#09142
SwitchesTP-LINKTL-SG2210P

Smart switch, 8x 10/100/1000 RJ-45, PoE+, desktop (TP-Link TL-SG2210P)

  • 61 W PoE Budget: 8× 802.3af/at-compliant PoE+ ports with a total power supply of 61 W*.
  • Full Gigabit Ports: 8× gigabit PoE+ ports and 2× gigabit SFP Slots provide high-speed connections.
  • Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)**, Centralized Cloud Management, and Intelligent Monitoring.
  • Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
  • Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm Control, DHCP Snooping, 802.1X, Radius Authentication, and more.
  • Optimized Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.
  • Versatile Management: WEB/CLI managed modes, SNMP, and RMON bring abundant management features.
Standards IEEE 802.3/i/u/ab/ad/x/d/s/w/q/p
Copper ports 8x 10/100/1000 Mbps RJ-45 (Auto Negotiation/Auto MDI/MDIX)
PoE Ports (RJ45) Standard 802.3af/at compliant,
PoE Ports 8 Ports,
Power Supply 61 W
Performance
Bandwidth/Backplane 20Gbps
Packet Forwarding Rate 14.88 Mpps
MAC Address Table 8k
Packet Buffer Memory 4.1 Mbit
Jumbo Frame 9 KB
Software features
Quality of Service Support 802.1p CoS/DSCP priority,
Support 4 priority queues,
Queue scheduling- SP,
WRR,
SP+WRR,
Port/Flow- based Rate Limiting
L2 Features IGMP Snooping V1/V2/V3,
802.3ad LACP (Up to 6 aggregation groups,
containing 4 ports per group),
Spanning Tree STP/RSTP/MSTP,
LLDP,
LLDP-Med,
BPDU Filtering/Guard,
TC/Root Protect,
Loop back detection,
802.3x Flow Control,
VLAN Voice
VLAN Supports up to 512 VLANs simultaneously (out of 4K VLAN IDs)
Security SSH v1/v2,
SSL v2/v3/TLSv1,
Port Security,
Broadcast/Multicast/Unknown-unicast Storm Control
Management
Omada App Yes
Centralized Management Omada Cloud-Based Controller,
Omada Hardware Controller (OC300),
Omada Hardware Controller (OC200),
Omada Software Controller
Cloud Access Yes (Through OC300,
OC200,
Omada Cloud-Based Controller,
or Omada Software Controller)
Management Features Web-based GUI,
Command Line Interface (CLI) through telnet,
SNMPv1/v2c/v3,
SNMP Trap/Inform,
RMON (1,2,3,9 groups),
SDM Template,
DHCP/BOOTP Client,
Dual Image,
Dual Configuration,
CPU Monitoring,
Cable Diagnostics,
EEE,
SNTP,
System Log
Dimensions 8.2x4.9x1.0 in. (209x126x26mm)
Operating temperature 0°C ÷ 40°C
Operating humidity 10% ÷ 90%,
non-condensing
Power External Power Adapter (Output 53.5 VDC/ 1.31 A)
Power Consumption 10,5 W (220 V/50 Hz),
75,3 W (220 V/50 Hz) (with 58 W PD connected)
Fan Quantity Fanless
Certificates CE,
FCC,
RoHS
Warranty period 5 years
Manufacturer TP-Link

« previous product  |  next product »     » show on list«» Switches «
Net Price: 120.00 USD  Unit: pcs
Minimal order quantity: 1 x pcs
Quantity in the smallest collective package: 1 x pcs
