#03117
NEW
Environmental MonitoringVUTLANVT855t

Monitoring unit 19" 1U; 8x analog; 1x CAN; 32x dry contact inputs (Vutlan VT855t)

VT855t / Data Center Monitoring System is used for environmental monitoring (e.g. temperature, humidity, voltage, leakage, smoke, airflow). It is also used as an I/O controller (e.g. door control, fans, generator, control panels, UPS, circuit breakers, and alarms). Can use up to 1000 different elements - notifications, triggers, timers, logic schemes, sensors, dry contacts. Has a built-in Web interface with virtual sensors, logic schemes, different types of notifications, and control panels.

Order options:
1 power inlet (VT825t) or 2 power inlets (VT825tt), providing a redundant power supply for A&B power distribution.
REMOTE CONTROL
IP monitoring Web,
SNMP,
SMS (LTE modem art. VT740 is ordered separately!)
Sensors control Administrative 3-level control of sensors using login
INTERFACE & PROTOCOL SUPPORT
Interface Access via any Internet browser.
LAN Ethernet 10/100Mbit
Network protocols HTTP; HTTPS; DynDNS; SSL; SNMP v1,
v2c,
v3; SMTP; FTP; Syslog; RADIUS; OpenVPN
OS Linux 6.2
Processor Cortex A7 1GHz
Total CPU cores 2
RAM 128MB
Software Built-in software for events processing.
Alert type FTP,
syslog,
SMTP or SNMP,
SMS (LTE modem #03105 is ordered separately)
A maximum number of "mail to" recipients 20
A maximum number of "SMS to" recipients in an SMS notification 20
Pings Built-in ping
LEDs CAN,
ACT,
E1,
E2,
Error,
Relays R1 and R2
Clock Built-in clock with time synchronization
Watchdog Built-in watchdog timer
The maximum amount of sensors 150
The maximum amount of elements 1000
USB cameras x1
IP cameras x4
POWER
Power req 90-240V,
IEC C14,
Fuse 1A or DC (24V/48V)
Power consumption 10W
Power reservation 12V,
built-in voltage monitor
INLETS/OUTLETS
Ethernet 100Mbit
USB USB 2.0 Type A
Mini USB AB USB 2.0 HS
Analog port 8x6P4C for connecting any analog sensor.
CAN BUS 2 x 6P6C for connecting up to 32 CAN sensors (over 12 sensors,
regeneration of the signal is required using the CAN # 03880 power module). Fuse protection on each line.
Relay outputs 2 ports
Alarm relay 2 x 12V 0.25A alarm port for VT103 Alarm Beacon (#08264) or VT105 (#08344)
Dry contact inputs 32 x dry contacts input + 8 x dry contacts output
EXTERNAL MEMORY
Micro SD card Micro SD card slot (SDXC up to 512 Gb - saving logs,
record video,
run software,
databases and scripts)
FEATURES
Installation 19" cabinet or desktop
Dimensions (WxHxD) 440mm 44mm 90mm
Net weight 1.5 kg
Working temperature Min. -10 C - Max. 80 C
Supply includes Monitoring unit,
power cable 240V,
RJ45 cord,
manual,
warranty,
4 self-adhesive rubber legs,
plugs,
19" mounting angles.
Warranty 3 years
#03105 LTE Modem VT740
#08264 Alarm beacon VT103
#08344 Alarm beacon VT105

Net Price: 585.00 USD  Unit: pcs
Minimal order quantity: 1 x pcs
Quantity in the smallest collective package: 1 x pcs
x pcs
