Standards | IEEE 802.3/i/u/ab/z/ad/x/af/d/s/w/q/x/p |
---|---|
Copper ports | 8x 10/100/1000 Mbps RJ-45 (Auto Negotiation/Auto MDI/MDIX) PoE+, 1x 10/100/1000 Mbps RJ-45 |
Free slots | 1x 1000 Mbps SFP |
PoE Ports (RJ45) | |
Standard | 802.3af/at compliant |
PoE Ports | 8 Ports |
Power Supply | 63W |
Performance | |
Bandwidth/Backplane | 20Gbps |
MAC Address Table | 4k |
Software features | |
Advanced Features | Compatible With IEEE 802.3af/at Compliant PDs, EEE802.3x Flow Control, 802.1p/DSCP QoS, IGMP Snooping |
Transmission Method | Store-And-Forward |
Housing / case type | 19", metal |
Dimensions | 209 x 126 x 26 mm |
Operating temperature | 0°C ÷ 40°C |
Operating humidity | 10% ÷ 90%, non-condensing |
Power | 100~240VAC, 50/60Hz, External Power Adapter(Output 48VDC/1.25A) |
Power Consumption | Maximum (PoE on) 78.13W, Maximum (PoE off) 7.11W |
Fan Quantity | 0 |
Certificates | CE, FCC, RoHS |
Manufacturer | TP-Link |
Net Price: 65.60 USD Unit: pcs
|
Minimal order quantity: 1 x pcs Quantity in the smallest collective package: 1 x pcs |
