Standards | IEEE 802.3i/802.3u/ 802.3ab/ 802.3x/ 802.1p/ 802.1q |
---|---|
Copper ports | 16x 10/100/1000 Mbps RJ-45 |
Auto MDI/MDI-X | yes |
Auto-negotiation (Nway) | yes |
Performance: | |
Switching Capacity | 32Gbps |
Packet Forwarding Rate | 23.81Mpps |
MAC Address Table | 8K |
Packet Buffer Memory | 4.1Mb |
Jumbo Frame | 10KB |
Software features: | |
Quality of Service | Support Port-based/802.1p/DSCP priority, Support 4 priority queues, Rate Limit, Storm Control |
L2 Features | IGMP Snooping V1/V2/V3, Static Link Aggregation, Port Mirroring, Cable Diagnostics, Loop Prevention |
VLAN | Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs), MTU/Port/Tag VLAN |
Transmission Method | Store-And-Forward |
Dimensions | 11.26 x 4.4 x 1.0 in. (286x111.7x25.4 mm) |
Operating temperature | 0°C ÷ 40°C |
Operating humidity | 10% ÷ 90%, non-condensing |
Power | External Power Adapter(Output 9VDC/0.6A) |
Max Power Consumption | 9.27W(220V/50Hz) |
Max Heat Dissipation | 31,36BTU/h |
Certificates | CE, FCC, RoHS |
Warranty | 5 years |
Manufacturer | TP-Link |
Net Price: 62.00 USD Unit: pcs
|
Minimal order quantity: 1 x pcs Quantity in the smallest collective package: 1 x pcs |
