| Wavelength | Tx 1490nm, Rx 1310nm |
|---|---|
| Connector | Device GPON SFP, Fiber SC/UPC |
| Fiber Type | Single Fiber (9/125um) |
| Data Rate | Tx 2488.32Mbps, Rx 1244.16Mbps |
| Power Level | Class C+ (Tx Optical Power +3~+7dBm，Rx Sensitivity <-30 dBm，Rx Saturation Optical Power>-12dBm) |
| Extinction Ratio | >8.2dB |
| Rx Optical Power Tolerance | >5dBm |
| Transmission Distance | Max. 20 km |
| Hot Swap | Yes |
| Nominal Voltage | 3.3 V (< ± 5％) |
| Diagnostic Function | Monitors parameters such as voltage, transceiver power, and temperature |
| Electrical Level | Data Interface LVPECL, Control Interface LVTTL |
| Package | 2× 10 SFF |
| Manufacturer | Tp-Link |
Net Price: 75.00 USD Unit: pcs
|
|
Minimal order quantity: 1 x pcs Quantity in the smallest collective package: 1 x pcs |
