| Standards | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p, |
|---|---|
| Fan Quantity | 0 |
| Copper ports | 4× 10/100/1000 Mbps RJ45 Ports, 1× Gigabit SFP/RJ45 Combo Slot, 1× Gigabit SFP Slot |
| Switching Capacity | 12Gbps |
| Packet Forwarding Rate | 8.93 Mpps |
| Mac Address Table | 8K |
| Jumbo Frame | 15 KB |
| Packet Buffer Memory | 4 Mb |
| Auto MDI/MDI-X | yes |
| Auto-negotiation (Nway) | yes |
| Switching architecture / speed | Store and Forward |
| Quality of Service | Support Port-Based/802.1p/DSCP priority, Support 4 priority queues, Rate Limit, Storm Control |
| L2 Features | IGMP Snooping V1/V2/V3, Static Link Aggregation, Port Mirroring, Cable Diagnostics, Loop Prevention, PoE Auto Recovery, Extend Mode |
| VLAN | Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs), MTU/Port/Tag VLAN |
| Management | |
| Omada App | Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| Centralized Management | Omada Cloud-Based Controller, Omada Hardware Controller, Omada Software Controller |
| Cloud Access | Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| Zero-Touch Provisioning | Yes. Requires the use of Omada Cloud-Based Controller |
| Management Features | Web-based GUI, DHCP Client, Cable Diagnostics, Automatic Device Discovery, Batch Configuration, Batch Firmware Upgrading, Unified Configuration |
| Installation | DIN-rail mounting, Wall mounting |
| Dimensions | 5.1 × 3.7 × 1.8 in (129 × 95 × 45 mm) |
| Operating temperature | -40°C ÷ 75°C |
| Operating humidity | 5% ÷ 95%, non-condensing |
| Power | 9.6-60V 1+1 Redundant DC Power Input |
| Certificates | CE, FCC, RoHS |
| Package Contents | IES206G, DIN-Rail Mounting Bracket, Wall-Mounting Plates, Installation Guide |
| Warranty | 5 years |
| Manufacturer | TP-Link |
