New items
- Computer Network Accessories
-
- » SFP+, QSFP+, SFP28 COPPER CABLES#07284
SFP28 25G Passive Copper Cable, 2,0 m (Wave Optics, WO-SFP28-25GB-CU-02M)
Support for multi-gigabit data rates up to 28Gbps
Data rates backward compatible to 1Gbps
Hot-pluggable SFP 20 PIN footprint
I/O Connector designed for high speed differential signal applications
Improved pluggable form factor(IPF) compliant for enhanced EMI/EMC performanceCompatible SFP28 MSA,
RoHSOperating case temperature 0°C÷70°C Length 2m Manufacturer Wave Optics
#07285SFP28 25G Passive Copper Cable, 3,0 m (Wave Optics, WO-SFP28-25GB-CU-03M)
Support for multi-gigabit data rates up to 28Gbps
Data rates backward compatible to 1Gbps
Hot-pluggable SFP 20 PIN footprint
I/O Connector designed for high speed differential signal applications
Improved pluggable form factor(IPF) compliant for enhanced EMI/EMC performanceCompatible SFP28 MSA,
RoHSOperating case temperature 0°C÷70°C Length 3m Manufacturer Wave Optics
#07286SFP28 25G Passive Copper Cable, 5,0 m (Wave Optics, WO-SFP28-25GB-CU-05M)
Support for multi-gigabit data rates up to 28Gbps
Data rates backward compatible to 1Gbps
Hot-pluggable SFP 20 PIN footprint
I/O Connector designed for high speed differential signal applications
Improved pluggable form factor(IPF) compliant for enhanced EMI/EMC performanceCompatible SFP28 MSA,
RoHSOperating case temperature 0°C÷70°C Length 5m Manufacturer Wave Optics
#07279QSFP28 100G Passive Copper Cable, 1,0 m (Wave Optics, WO-QSFP28-100GB-CU-01M)
Support for multi-gigabit data rates up to 100Gbps
Data rates backward compatible to 1Gbps
Hot-pluggable SFP 20 PIN footprint
I/O Connector designed for high speed differential signal applications
Improved pluggable form factor(IPF) compliant for enhanced EMI/EMC performanceCompatible QSFP28 MSA,
RoHSOperating case temperature 0°C÷70°C Length 1m Manufacturer Wave Optics
#07280QSFP28 100G Passive Copper Cable, 2,0 m (Wave Optics, WO-QSFP28-100GB-CU-02M)
Support for multi-gigabit data rates up to 100Gbps
Data rates backward compatible to 1Gbps
Hot-pluggable SFP 20 PIN footprint
I/O Connector designed for high speed differential signal applications
Improved pluggable form factor(IPF) compliant for enhanced EMI/EMC performanceCompatible QSFP28 MSA,
RoHSOperating case temperature 0°C÷70°C Length 2m Manufacturer Wave Optics
#07281QSFP28 100G Passive Copper Cable, 3,0 m (Wave Optics, WO-QSFP28-100GB-CU-03M)
Support for multi-gigabit data rates up to 100Gbps
Data rates backward compatible to 1Gbps
Hot-pluggable SFP 20 PIN footprint
I/O Connector designed for high speed differential signal applications
Improved pluggable form factor(IPF) compliant for enhanced EMI/EMC performanceCompatible QSFP28 MSA,
RoHSOperating case temperature 0°C÷70°C Length 3m Manufacturer Wave Optics
#07282QSFP28 100G Passive Copper Cable, 5,0 m (Wave Optics, WO-QSFP28-100GB-CU-05M)
Support for multi-gigabit data rates up to 100Gbps
Data rates backward compatible to 1Gbps
Hot-pluggable SFP 20 PIN footprint
I/O Connector designed for high speed differential signal applications
Improved pluggable form factor(IPF) compliant for enhanced EMI/EMC performanceCompatible QSFP28 MSA,
RoHSOperating case temperature 0°C÷70°C Length 5m Manufacturer Wave Optics
-
- » UNMANAGED MEDIA CONVERTERS, SINGLE AND MULTI MODE#07606
Gigabit media converter 10/100/1000 Mbps RJ-45/SC, MM 1310nm, 2km (Wave Optics, WO-KB-MDS-002K)
Standards IEEE 802.3ab/z Port #1 10/100/1000 Mbps RJ-45 Port #1 max. distance 100m Port #1 cable type UTP/STP cat. 5 Port #2 1000 Mbps SC MM TX wavelength 1310nm RX wavelength 1310nm Port #2 max. distance 2km Port #2 cable type 50/125, 62.5/125, 100/140 µm Housing / case type desktop Operating temperature 0°C ÷ 45°C Operating humidity 10% ÷ 90%,
non-condensingCertificates FCC Class B,
CEWarranty period 2 years
#07605Gigabit media converter 10/100/1000 Mbps RJ-45/SC, MM 850nm, 550m (Wave Optics, WO-KB-MDS-550)
Standards IEEE 802.3ab/z Port #1 10/100/1000 Mbps RJ-45 Port #1 max. distance 100m Port #1 cable type UTP/STP cat. 5 Port #2 1000 Mbps SC MM TX wavelength 850nm RX wavelength 850nm Port #2 max. distance 550m Port #2 cable type 50/125, 62.5/125, 100/140 µm Housing / case type desktop Operating temperature 0°C ÷ 45°C Operating humidity 10% ÷ 90%,
non-condensingCertificates FCC Class B,
CEWarranty period 2 years
#07607Gigabit media converter 10/100/1000 Mbps RJ-45/SC, SM 1310nm, 10km (Wave Optics, WO-KB-SDS-010K)
Standards IEEE 802.3ab/z Port #1 10/100/1000 Mbps RJ-45 Port #1 max. distance 100m Port #1 cable type UTP/STP cat. 5 Port #2 1000 Mbps SC SM TX wavelength 1310nm RX wavelength 1310nm Port #2 max. distance 10km Port #2 cable type 8.3/125, 8.7/125, 9/125, 10/125 µm Housing / case type desktop Operating temperature 0°C ÷ 45°C Operating humidity 10% ÷ 90%,
non-condensingCertificates FCC Class B,
CEWarranty period 2 years
-
