Industrial IoT - Smart Lighting Controller LoRa Slave Series


Smart Lighting Controller
Oring Networking » Industrial IoT » Smart Lighting Controller LoRa Slave Series

Overview

Smart Lighting Controller LoRa Slave SeriesORing’s smart lighting series managed wireless transporting is designed for street lamp. OLS-L series stands as cell controller in the smart street lamp application. It is proposed to connect on the top of LED lamp device with standard NEMA socket (ANSI C136.41), which is compliant with DALI (Digital Addressable Lighting Interface) dimming control function, is according to international standard design. The advantage of digital dimming is that fixtures are addressable. You can also have many more different levels of light output when using digital dimming. The benefits of DALI dimming control are lower energy cost to user, higher level of maintenance to the facility manager, and more flexible sensor controlled dimming and switching. On the other hand, OLS-L series is also compliant with traditional 0-10V dimming control function. It is based on analogue signal percentage increased or decreased as the voltage on the analog signal increases or decreases.

In addition, OLS-L series supports electrical parameters monitoring - Vrms(V), Irms(I), Power Factor(PF), Frequency(Hz), Power(W). According to above monitored parameters, it also provides fault detection information – Over/under voltage, Over/under current, Lamp/Driver fault, Device failure. Furthermore, it is the autonomous sensing device, which is dimming with sunrise time, smart dimming procedure through analyzing data, and so on.

OLS-L series is designed by the whole intelligent system, including smart power saving mode, fault detection, intelligent operating based on predestinate schedule, dimming control, turn-on, turn-off, and so on. Moreover, each lighting controller is easily managed through content management system (CMS).For the reason that ORing Industrial Networking Corp. also provides users to apply to the intelligent products easily, proposing ORing IIoT MagiCity, which is based on MQTT and CoAP architecture implementation and is going to realize economic data more clearly.  Let users operate each device reliably in the whole world, only get the certification from ORing IIoT MagiCity.


Features

  • Designed and optimized by Low Power Wild Area Network (LPWAN) with LoRa network technology
  • NEMA socket connected (ANSI C136.41)
  • Smart Control function (ON/OFF/Dimming)
  • Smart power saving mode
  • Electrical parameters monitoring
  • Fault detection
  • Intelligent operation based on predestinate schedule
    • Wild operating temp range -30°C to +70°C
    • Platform connection - supporting MQTT and CoAP transfer protocol
    • Supporting content management system (CMS)
    • Supporting integrated ambient light sensor and accelerometer

Specification


Model Name OLS-L SERIES
NEMA Socket connected

Pin Define

7pin NEMA socket ( Follow ANSI C136.41 Receptacle )
Controller Feature

Dimmable Function Feature

DALI AO(0-10Vdc)

Electrical parameters monitor

Vrms(V), Irms(I), Power Factor(PF), Frequency(Hz), Power(W)

Lighting Control



ON
OFF
LoRa Technology
Specification

Slave

Transmission Distance Up to 1.5km (open space)
Data Rate 1-37.5kbps (programmable), 1kbps(Typ.)
TX Power Gain Range Typ. : 14dBm ; Max. : 20dBm
RX Sensitivity Up to -137dBm
Security 128-bit AES encryption algorithms
Network Interface
Working Mode LoRa
Frequency Bandwidth 902-928MHz
863-870MHz
779-787MHz
433MHz
Electrical Specification
AC Input Voltage 90-264Vac
Output Load Current Max. 2A
Power Consumption Max. 1.35W
Supply Current DALI 10mA.
AO(0-10Vdc) 1mA.
Protection
Inrush Current Protection 5A@10ms pulse
Surge Protection 1kV
Physical Characteristic
Enclosure IP54
Dimensions Φ90 x 87mm
Weight (g) 190 g
Environmental
Storage Temperature -40°C to +80°C (-40 to 176°F)
Operating Temperature -30°C to +70°C (-22 to 158°F)
Operating Humidity 0 to 95%


Smart Lighting Controller LoRa Slave Series


Model Name Description
OLS-L01ND ORing Lighting Controller LoRa Slave, 920MHz, NEMA Receptacle, DALI, OLS-L01ND
OLS-L01ND-G ORing Lighting Controller LoRa Slave, 920MHz, NEMA, DALI, with G-sensor, OLS-L01ND-G
OLS-L01ND-GP ORing Lighting Controller LoRa Slave, 920MHz, NEMA, DALI,with GP-sensor, OLS-L01ND-GP
OLS-L01ND-P ORing Lighting Controller LoRa Slave, 920MHz, NEMA, DALI, with Photo-Sensor, OLS-L01ND-P
OLS-L01NT ORing Lighting Controller LoRa Slave, 920MHz, NEMA Receptacle, 0-10V, OLS-L01NT
OLS-L01NT-G ORing Lighting Controller LoRa Slave, 920MHz, NEMA, 0-10V, with G-Sensor, OLS-L01NT-G
OLS-L01NT-GP ORing Lighting Controller LoRa Slave, 920MHz, NEMA, 0-10V,with GP-sensor, OLS-L01NT-GP
OLS-L01NT-P ORing Lighting Controller LoRa Slave, 920MHz, NEMA, 0-10V, with Photo-Sensor, OLS-L01NT-P


LoRa Slave Lighting Series DataSheet
