Mastech MY-68 - Digital Multimeter
Perfect for engineers and technicians. Digital multimeter 3 and 3/4 with an automatic range alteration and the possibility of attaching a clamp meter. Frequency measurement up to 200kHz.
| Max. LCD display | 3999 |
|---|---|
| Range selection | manual/automatic |
| DC voltage | 400m/4/40/400V ±0,7%, 1000V ±0,8% |
| AC voltage | 400m ±3,0%, 4/40/400V ±0,8%, 750V ±1,0% |
| DC current | 0,4/4/40/400mA ±1,2%, 10A ±2,0% |
| AC current | 0,4/4/40/400mA ±1,5%, 10A ±3,0% |
| Resistance | 400/4k/40k/400k/4MΩ ±1,2%, 40MΩ ±2,0% |
| Capacity | 4n ±5,0%, 40n/400n/4µ/40µ/200µF ±3,0% |
| Frequency | 10/100/1k/10k/100k/200kHz ±2,0% |
| Bandwidth | 40 ÷ 1000 Hz |
| Diode test | 1mA / 1,5V |
| hFE test | Ib=10µA / Vce=2,8V |
| Sound signaling | < 50 Ω |
| Data hold | yes |
| Battery indicator | yes |
| Protection | yes |
| Impedance | 10 MΩ |
| Power | 9V 6F22 battery |
| Manufacturer | Mastech |
Net Price: 23.30 USD Unit: pcs
|
|
Minimal order quantity: 1 x pcs Quantity in the smallest collective package: 1 x pcs |
