New Items in Atel Electronics

NEW ITEMS


  • Computer Network Accessories
    • Switches
      • » GIGABIT ETHERNET / L2 MANAGED SWITCHES
          #09773

          Managed switch, 5x 2,5G, 2 slide-in 10G SFP+ slot, PoE++, 19" (TP-Link ES206XPP-M2)

          • 5× 2.5 Gbps RJ45 ports (4× 802.3af/at/bt-compliant PoE++)
          • 1× 10 Gbps SFP+ Slot
          • 120W PoE budget, with up to 90W for each PoE port
          • Easy to Use: Supports plug-and-play for instant connectivity and simple configuration for additional features
          • Centralized Cloud Management via the web or the Omada app
          • Automatic Loop Prevention, VLAN, Port Isolation, QoS, and IGMP Snooping
          • Fanless design for silent operation
          • Durable metal casing and desktop/wall mounting design
          Standards IEEE 802.3 10Base-T,
          IEEE802.3u 100Base-TX
          Copper ports 5× 2.5 Gbps RJ45 PoE+ Ports
          Free slots 1× 10 Gbps SFP+ Slot
          Fan Quantity Fanless Design
          orty PoE+ (RJ45)
          Standard 802.3at/af compliant
          PoE Ports PoE+ Ports(802.3at PoE) 4 Ports
          Power Budget 120W available for all PoE++ ports,
          90W max per port
          Performance
          Switching Capacity 45 Gbps
          Packet Forwarding Rate 33.48 Mpps
          MAC Address Table 16 K
          Packet Buffer Memory 640 KB
          Jumbo Frame 10 KB
          Software features
          Quality of Service Support 802.1p CoS/DSCP priority,
          Support 4 priority queues,
          Queue scheduling- SP,
          WRR,
          SP+WRR,
          Port/Flow- based Rate Limiting
          L2 and L2+ Features DHCP Relay,
          DHCP VLAN Relay,
          DHCP L2 Relay,
          Link Aggregation,
          Static link aggregation,
          802.3ad LACP,
          Up to 8 aggregation groups and up to 8 ports per group,
          Spanning Tree Protocol,
          802.1D STP,
          802.1w RSTP,
          802.1s MSTP,
          STP Security TC Protect,
          BPDU Filter/Protect,
          Root Protect,
          Loopback Detection,
          Flow Control,
          802.3x Flow Control,
          Mirroring,
          Port Mirroring,
          CPU Mirroring,
          One-to-One,
          Many-to-One,
          Flow-Based,
          Ingress/Egress/Both,
          Device Link Detect Protocol (DLDP),
          802.1ab LLDP/ LLDP-MED
          L2 Multicast 511 IPv4,
          IPv6 shared multicast groups,
          IGMP Snooping,
          IGMP v1/v2/v3 Snooping,
          Fast Leave,
          IGMP Snooping Querier,
          Static Group Config,
          Multicast VLAN Registration (MVR),
          Multicast Filtering,
          MLD Snooping,
          MLD v1/v2 Snooping,
          Fast Leave,
          MLD Snooping Querier,
          Static Group Config,
          Limited IP Multicast (256 profiles and 16 entries per profile)
          IPv6 Support IPv6 Dual IPv4/IPv6,
          Multicast Listener Discovery (MLD) Snooping,
          IPv6 neighbor discovery (ND),
          Path maximum transmission unit (MTU) discovery,
          Internet Control Message Protocol (ICMP) version 6,
          TCPv6/UDPv6,
          IPv6 applications,
          DHCPv6 Client,
          Ping6,
          Tracert6,
          Telnet (v6),
          IPv6 SNMP,
          IPv6 SSH,
          IPv6 SSL,
          Http/Https,
          IPv6 TFTP
          VLAN VLAN Group,
          Max. 4K VLAN Groups,
          802.1Q tag VLAN,
          MAC VLAN,
          Protocol VLAN,
          GVRP,
          Voice VLAN
          Security AAA,
          802.1X,
          Port based authentication,
          MAC (Host) based authentication,
          Authentication Method includes PAP/EAP-MD5,
          MAB,
          Guest VLAN,
          Support Radius authentication and accountability,
          IP/IPv6-MAC Binding,
          512 Binding Entries,
          DHCP Snooping,
          DHCPv6 Snooping,
          ARP Inspection,
          ND Detection,
          IP Source Guard,
          253 Entries,
          Source IP+Source MAC,
          IPv6 Source Guard,
          183 Entries,
          Source IPv6 Address+Source MAC,
          DoS Defend,
          Static/Dynamic/Permanent Port Security,
          Up to 64 MAC addresses per port,
          Broadcast/Multicast/Unicast Storm Control,
          kbps/ratio control mode,
          Port Isolation,
          Secure web management through HTTPS with SSLv3/TLS 1.2,
          Secure Command Line Interface (CLI) management with SSHv1/SSHv2,
          IP/Port/MAC based access control
          Management
          Omada App Yes
          Centralized Management Omada Cloud-Based Controller,
          Omada Hardware Controller (OC300),
          Omada Hardware Controller (OC200),
          Omada Software Controller
          Cloud Access Yes (Through OC300,
          OC200,
          Omada Cloud-Based Controller,
          or Omada Software Controller)
          Management Features Web-based GUI,
          Command Line Interface (CLI) through telnet,
          SNMPv1/v2c/v3,
          SNMP Trap/Inform,
          RMON (1,2,3,9 groups),
          SDM Template,
          DHCP/BOOTP Client,
          Dual Image,
          Dual Configuration,
          CPU Monitoring,
          Cable Diagnostics,
          EEE,
          SNTP,
          System Log
          Housing / case type Desktop/Wall-Mounting
          Dimensions 8.2 × 5.0 × 1.0 in (209 × 126 × 26 mm)
          Operating temperature 0°C ÷ 40°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power AC/DC Adapter (Input 100-240V AC; Output 53.5V DC/2.43A)
          Certificates FCC,
          CE,
          RoHS
          Warranty period 5 years
          Manufacturer TP-Link
          TP-LINK
          Managed switch, 5x 2,5G, 2 slide-in 10G SFP+ slot, PoE++, 19" (TP-Link ES206XPP-M2)
          Net Price: 162.00 USD
          product card»
          #09772

          Managed switch, 8x 2,5G, 2 slide-in 10G SFP+ slot, PoE++, 19" (TP-Link ES210XPP-M2)

          • 8× 2.5 Gbps RJ45 ports (8× 802.3af/at/bt-compliant PoE++)
          • 1× 10 Gbps RJ45 Port, 1× 10 Gbps SFP+ Slot
          • 200W PoE budget, with up to 90W for each PoE port
          • Easy to Use: Supports plug-and-play for instant connectivity and simple configuration for additional features
          • Centralized Cloud Management via the web or the Omada app
          • Automatic Loop Prevention, VLAN, Port Isolation, QoS, and IGMP Snooping
          • Fanless design for silent operation
          • Durable metal casing and desktop/wall mounting design
          Standards IEEE 802.3 10Base-T,
          IEEE802.3u 100Base-TX
          Copper ports 8× 2.5 Gbps RJ45 PoE+ Ports,
          1× 10 Gbps RJ45 Port
          Free slots 1× 10 Gbps SFP+ Slot
          Fan Quantity Fanless Design
          orty PoE+ (RJ45)
          Standard 802.3at/af compliant
          PoE Ports PoE+ Ports(802.3at PoE) 8 Ports
          Power Budget 200W available for all PoE++ ports,
          90W max per port
          Performance
          Switching Capacity 80 Gbps
          Packet Forwarding Rate 59,52 Mpps
          MAC Address Table 16 K
          Packet Buffer Memory 12 Mbit
          Jumbo Frame 9 KB
          Software features
          Quality of Service Support 802.1p CoS/DSCP priority,
          Support 4 priority queues,
          Queue scheduling- SP,
          WRR,
          SP+WRR,
          Port/Flow- based Rate Limiting
          L2 and L2+ Features DHCP Relay,
          DHCP VLAN Relay,
          DHCP L2 Relay,
          Link Aggregation,
          Static link aggregation,
          802.3ad LACP,
          Up to 8 aggregation groups and up to 8 ports per group,
          Spanning Tree Protocol,
          802.1D STP,
          802.1w RSTP,
          802.1s MSTP,
          STP Security TC Protect,
          BPDU Filter/Protect,
          Root Protect,
          Loopback Detection,
          Flow Control,
          802.3x Flow Control,
          Mirroring,
          Port Mirroring,
          CPU Mirroring,
          One-to-One,
          Many-to-One,
          Flow-Based,
          Ingress/Egress/Both,
          Device Link Detect Protocol (DLDP),
          802.1ab LLDP/ LLDP-MED
          L2 Multicast 511 IPv4,
          IPv6 shared multicast groups,
          IGMP Snooping,
          IGMP v1/v2/v3 Snooping,
          Fast Leave,
          IGMP Snooping Querier,
          Static Group Config,
          Multicast VLAN Registration (MVR),
          Multicast Filtering,
          MLD Snooping,
          MLD v1/v2 Snooping,
          Fast Leave,
          MLD Snooping Querier,
          Static Group Config,
          Limited IP Multicast (256 profiles and 16 entries per profile)
          IPv6 Support IPv6 Dual IPv4/IPv6,
          Multicast Listener Discovery (MLD) Snooping,
          IPv6 neighbor discovery (ND),
          Path maximum transmission unit (MTU) discovery,
          Internet Control Message Protocol (ICMP) version 6,
          TCPv6/UDPv6,
          IPv6 applications,
          DHCPv6 Client,
          Ping6,
          Tracert6,
          Telnet (v6),
          IPv6 SNMP,
          IPv6 SSH,
          IPv6 SSL,
          Http/Https,
          IPv6 TFTP
          VLAN VLAN Group,
          Max. 4K VLAN Groups,
          802.1Q tag VLAN,
          MAC VLAN,
          Protocol VLAN,
          GVRP,
          Voice VLAN
          Security AAA,
          802.1X,
          Port based authentication,
          MAC (Host) based authentication,
          Authentication Method includes PAP/EAP-MD5,
          MAB,
          Guest VLAN,
          Support Radius authentication and accountability,
          IP/IPv6-MAC Binding,
          512 Binding Entries,
          DHCP Snooping,
          DHCPv6 Snooping,
          ARP Inspection,
          ND Detection,
          IP Source Guard,
          253 Entries,
          Source IP+Source MAC,
          IPv6 Source Guard,
          183 Entries,
          Source IPv6 Address+Source MAC,
          DoS Defend,
          Static/Dynamic/Permanent Port Security,
          Up to 64 MAC addresses per port,
          Broadcast/Multicast/Unicast Storm Control,
          kbps/ratio control mode,
          Port Isolation,
          Secure web management through HTTPS with SSLv3/TLS 1.2,
          Secure Command Line Interface (CLI) management with SSHv1/SSHv2,
          IP/Port/MAC based access control
          Management
          Omada App Yes
          Centralized Management Omada Cloud-Based Controller,
          Omada Hardware Controller (OC300),
          Omada Hardware Controller (OC200),
          Omada Software Controller
          Cloud Access Yes (Through OC300,
          OC200,
          Omada Cloud-Based Controller,
          or Omada Software Controller)
          Management Features Web-based GUI,
          Command Line Interface (CLI) through telnet,
          SNMPv1/v2c/v3,
          SNMP Trap/Inform,
          RMON (1,2,3,9 groups),
          SDM Template,
          DHCP/BOOTP Client,
          Dual Image,
          Dual Configuration,
          CPU Monitoring,
          Cable Diagnostics,
          EEE,
          SNTP,
          System Log
          Housing / case type Desktop/Wall-Mounting
          Dimensions 8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm)
          Operating temperature 0°C ÷ 40°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power AC/DC Adapter (Input 100-240V AC; Output 54V DC/4.16A)
          Certificates FCC,
          CE,
          RoHS
          Warranty period 5 years
          Manufacturer TP-Link
          TP-LINK
          Managed switch, 8x 2,5G, 2 slide-in 10G SFP+ slot, PoE++, 19" (TP-Link ES210XPP-M2)
          Net Price: 212.00 USD
          product card»
          #09355

          Managed switch, 48x 10/100/1000 RJ-45 ports, 6x 25G SFP28 ports, 19" (Edge-corE ECS4650-54T)

          • Best price-performance Gigabit Ethernet access switch with 25G uplinks
          • Full Gigabit Ports: 48x gigabit RJ45 ports and 6x 25gigabit SFP28 ports provide high-speed connections
          • Simple management (CLI, SNMP, Web, ecCLOUD, TIP OLS)
          Standards IEEE 802.3ae 10GBase-SR/LR,
          IEEE802.3ay 25GBase-SR,
          IEEE 802.3cc 25GBASE-LR,
          IEEE 802.3z 1000BASE-SX/LX
          Copper ports 48x 10/100/1000 Mbps RJ-45
          SFP ports 6x 25G SFP28
          PoE ports 48x 10/100/1000 Mbps RJ-45
          Additional ports 1× RJ45 Console Port,
          1x Managment port,
          USB Managment port
          Software features
          Quality of Service 8 hardware queues per port,
          IEEE 802.1p CoS,
          IP Precedence,
          DSCP,
          MAC Access control list,
          IP standard access control list,
          IP extended access control list,
          Strict Priority,
          Weighted Round Robin,
          Strict + WRR,
          GE Resolution 64 Kbps ~ 1.000 Mbps,
          10G Resolution 64 Kbps ~ 10.000 Mbps,
          25GE Resolution 64 Kbps~25.000 Mbps,
          Auto Traffic Control
          L2 Features 10/100/1000BASE-T copper interfaces,
          Auto-negotiation for port speed and duplex mode,
          Auto MDI/MDI-X,
          Multi-speed (1G/10G/25G) fiber interfaces,
          IEEE 802.3ae (10GBASE-SR/LR),
          IEEE 802.3ay (25GBASE-SR),
          IEEE 802.3cc (25GBASE-LR),
          IEEE 802.3z (1000BASE-SX/LX) transceivers 10G/25G DAC/AOC,
          Digital Diagnostic Monitoring on 25G SFP28 port,
          IEEE 802.3x for full duplex mode,
          Back-Pressure for half duplex mode,
          Jumbo frames 10KB,
          Broadcast/Multicast/Unknown Unicast storm control ,
          IEEE 802.1D (STP),
          IEEE 802.1w (RSTP),
          IEEE 802.1s (MSTP) 64 instances,
          BPDU Guard,
          BPDU filtering,
          Root Guard,
          BPDU transparent,
          Loopback detection,
          Non-Spanning Tree loopback detection,
          ITU-T G.8032v2 Ethernet Ring Protection Switch,
          Sub 50 msec convergence,
          Revertive operation mode,
          Multiple-ring network,
          Q-in-Q,
          xSTP,
          CDP,
          VTP and PVST+,
          LLDP,
          CDP/PVST+ Filtering,
          Selective Q-in-Q,
          Static Trunk,
          IEEE 802.3ad LACP,
          28 trunk groups up to 8 GE/ 6 25GE ports per group,
          SA+DA,
          SA,
          DA,
          SIP+DIP,
          SIP,
          DIP,
          Multi-chassis Link Aggregation,
          Static LACP,
          IGMP Authentication,
          IGMP v1/v2/v3 snooping,
          IGMP Proxy reporting,
          IGMP Filtering,
          IGMP Throttling,
          IGMP Immediate Leave,
          IGMP Querier,
          MVR supports 5 multicast VLANs,
          VLAN Mirror,
          Mac Based Mirror,
          ACL Mirror,
          Remote port mirror (RSPAN)
          VLAN Supports 4K VLAN,
          Port-based VLAN,
          IEEE 802.1Q VLAN,
          GVRP,
          IEEE 802.1v Protocol-based VLAN,
          IP Subnet-based VLAN,
          MAC-based VLAN,
          Traffic Segmentation
          IPv6 Support IIPv4/IPv6 dual protocol stack,
          IPv6 Address Types Stack (Unicast),
          IPv6 Neighbor Discovery,
          Duplicate address,
          Address resolution,
          Unreachable neighbor detection,
          Stateless auto-configuration,
          Manual configuration,
          Remote IPv6 ping,
          IPv6 Telnet support,
          HTTP over IPv6,
          SNMP over IPv6,
          IPv6 Syslog support,
          IPv6 TFTP support,
          MLD Snooping v1/v2,
          IPv6 Source Guard,
          DHCPv6 Snooping,
          MVR6
          Security Port security,
          IEEE 802.1X port based and MAC based authentication,
          IEEE 802.1X Supplicant,
          Dynamic VLAN Assignment,
          Auto QoS,
          MAC authentication,
          Web authentication,
          Voice VLAN,
          Guest VLAN,
          MAC Access control list,
          IP standard access control list,
          IP extended access control list,
          IPv6 ACL,
          DHCP Snooping,
          DHCP Info,
          DHCP Option 82,
          DHCP Option 82 Relay,
          IP Source Guard,
          PPPoE IA,
          Dynamic ARP Inspection,
          Denial of Service,
          Login Security,
          RADIUS authentication,
          RADIUS accounting,
          TACACS + authentication,
          TACACS + accounting,
          TACACS + authorization,
          Management Interface Access Filtering (SNMP/Web/Telnet),
          SSH (v1.5/v2.0) for security Telnet,
          SSL for HTTPS,
          SNMPv3
          Management
          Management Features Zero Touch provisioning,
          mDNS,
          CLI via console port or Telnet management,
          Web management,
          SNMP (v1/v2c/v3),
          Firmware upgrade via TFTP/HTTP/FTP/SFTP server,
          Multiple configuration files,
          Configuration file upload/download via TFTP/HTTP/FTP/SFTP server,
          RMON (groups 1,2,3 and 9),
          DHCP client for IP address assignment,
          DHCP dynamic provision Option (66/67),
          SNTP,
          Syslog (local Flash),
          Remotelog (RFC3164),
          SMTP (E-mail Notification),
          Supports LLDP (802.1ab),
          sFlow (v4/v5),
          IPv6 sFlow
          Switching capacity [Gbps] 396
          Packet Forwarding Rate 295 Mpps
          MAC Address Table 32K
          Jumbo Frame 10 KB
          Dimensions 442 × 420 × 43.6 mm
          Weight 4.7 kg
          Operating temperature -5°C ÷ 45°C
          Operating humidity 5% ÷ 95%,
          non-condensing
          Power 100~240VAC 50/60Hz
          Max Power Consumption 52 W
          Certificates FCC Class A,
          CE,
          Safety Compliance (CB/UL)
          Warranty period 3 years
          Manufacturer Edge-core
          EDGE-CORE
          Managed switch, 48x 10/100/1000 RJ-45 ports, 6x 25G SFP28 ports, 19" (Edge-corE ECS4650-54T)
          Net Price: 1 550.00 USD
          product card»
      • » GIGABIT ETHERNET / L3 MANAGED SWITCHES
          #07034

          Managed switch, 48x 10/100/1000 RJ-45 ports, 6x 25G SFP28 ports, 19" (Edge-core ECS4150-54T)

          • Best price-performance Gigabit Ethernet access switch with 25G uplinks
          • Full Gigabit Ports: 48x gigabit RJ45 ports and 6x 25gigabit SFP28 ports provide high-speed connections
          • Simple management (CLI, SNMP, Web, ecCLOUD, TIP OLS)
          Standards IEEE 802.3ae 10GBase-SR/LR,
          IEEE802.3ay 25GBase-SR,
          IEEE 802.3cc 25GBASE-LR,
          IEEE 802.3z 1000BASE-SX/LX
          Copper ports 48x 10/100/1000 Mbps RJ-45
          SFP ports 6x 25G SFP28
          Additional ports 1× RJ45 Console Port,
          1x Managment port,
          USB Managment port
          Software features
          Quality of Service 8 hardware queues per port,
          IEEE 802.1p CoS,
          IP Precedence,
          DSCP,
          MAC Access control list,
          IP standard access control list,
          IP extended access control list,
          Strict Priority,
          Weighted Round Robin,
          Strict + WRR,
          GE Resolution 64 Kbps ~ 1.000 Mbps,
          10G Resolution 64 Kbps ~ 10.000 Mbps,
          25GE Resolution 64 Kbps~25.000 Mbps,
          Auto Traffic Control
          L2 Features 10/100/1000BASE-T copper interfaces,
          Auto-negotiation for port speed and duplex mode,
          Auto MDI/MDI-X,
          Multi-speed (1G/10G/25G) fiber interfaces,
          IEEE 802.3ae (10GBASE-SR/LR),
          IEEE 802.3ay (25GBASE-SR),
          IEEE 802.3cc (25GBASE-LR),
          IEEE 802.3z (1000BASE-SX/LX) transceivers 10G/25G DAC/AOC,
          Digital Diagnostic Monitoring on 25G SFP28 port,
          IEEE 802.3x for full duplex mode,
          Back-Pressure for half duplex mode,
          Jumbo frames 10KB,
          Broadcast/Multicast/Unknown Unicast storm control ,
          IEEE 802.1D (STP),
          IEEE 802.1w (RSTP),
          IEEE 802.1s (MSTP) 64 instances,
          BPDU Guard,
          BPDU filtering,
          Root Guard,
          BPDU transparent,
          Loopback detection,
          Non-Spanning Tree loopback detection,
          ITU-T G.8032v2 Ethernet Ring Protection Switch,
          Sub 50 msec convergence,
          Revertive operation mode,
          Multiple-ring network,
          Q-in-Q,
          xSTP,
          CDP,
          VTP and PVST+,
          LLDP,
          CDP/PVST+ Filtering,
          Selective Q-in-Q,
          Static Trunk,
          IEEE 802.3ad LACP,
          28 trunk groups up to 8 GE/ 6 25GE ports per group,
          SA+DA,
          SA,
          DA,
          SIP+DIP,
          SIP,
          DIP,
          Multi-chassis Link Aggregation,
          Static LACP,
          IGMP Authentication,
          IGMP v1/v2/v3 snooping,
          IGMP Proxy reporting,
          IGMP Filtering,
          IGMP Throttling,
          IGMP Immediate Leave,
          IGMP Querier,
          MVR supports 5 multicast VLANs,
          VLAN Mirror,
          Mac Based Mirror,
          ACL Mirror,
          Remote port mirror (RSPAN)
          VLAN Supports 4K VLAN,
          Port-based VLAN,
          IEEE 802.1Q VLAN,
          GVRP,
          IEEE 802.1v Protocol-based VLAN,
          IP Subnet-based VLAN,
          MAC-based VLAN,
          Traffic Segmentation
          IPv6 Support IIPv4/IPv6 dual protocol stack,
          IPv6 Address Types Stack (Unicast),
          IPv6 Neighbor Discovery,
          Duplicate address,
          Address resolution,
          Unreachable neighbor detection,
          Stateless auto-configuration,
          Manual configuration,
          Remote IPv6 ping,
          IPv6 Telnet support,
          HTTP over IPv6,
          SNMP over IPv6,
          IPv6 Syslog support,
          IPv6 TFTP support,
          MLD Snooping v1/v2,
          IPv6 Source Guard,
          DHCPv6 Snooping,
          MVR6
          Security Port security,
          IEEE 802.1X port based and MAC based authentication,
          IEEE 802.1X Supplicant,
          Dynamic VLAN Assignment,
          Auto QoS,
          MAC authentication,
          Web authentication,
          Voice VLAN,
          Guest VLAN,
          MAC Access control list,
          IP standard access control list,
          IP extended access control list,
          IPv6 ACL,
          DHCP Snooping,
          DHCP Info,
          DHCP Option 82,
          DHCP Option 82 Relay,
          IP Source Guard,
          PPPoE IA,
          Dynamic ARP Inspection,
          Denial of Service,
          Login Security,
          RADIUS authentication,
          RADIUS accounting,
          TACACS + authentication,
          TACACS + accounting,
          TACACS + authorization,
          Management Interface Access Filtering (SNMP/Web/Telnet),
          SSH (v1.5/v2.0) for security Telnet,
          SSL for HTTPS,
          SNMPv3
          Management
          Management Features Zero Touch provisioning,
          mDNS,
          CLI via console port or Telnet management,
          Web management,
          SNMP (v1/v2c/v3),
          Firmware upgrade via TFTP/HTTP/FTP/SFTP server,
          Multiple configuration files,
          Configuration file upload/download via TFTP/HTTP/FTP/SFTP server,
          RMON (groups 1,2,3 and 9),
          DHCP client for IP address assignment,
          DHCP dynamic provision Option (66/67),
          SNTP,
          Syslog (local Flash),
          Remotelog (RFC3164),
          SMTP (E-mail Notification),
          Supports LLDP (802.1ab),
          sFlow (v4/v5),
          IPv6 sFlow
          Switching capacity [Gbps] 396
          Packet Forwarding Rate 295 Mpps
          MAC Address Table 32K
          Jumbo Frame 10 KB
          Dimensions 442 × 420 × 43.6 mm
          Weight 4.7 kg
          Operating temperature -5°C ÷ 45°C
          Operating humidity 5% ÷ 95%,
          non-condensing
          Power 100~240VAC 50/60Hz
          Max Power Consumption 52 W
          Certificates FCC Class A,
          CE,
          Safety Compliance (CB/UL)
          Warranty period 3 years
          Manufacturer Edge-core
          EDGE-CORE
          Managed switch, 48x 10/100/1000 RJ-45 ports, 6x 25G SFP28 ports, 19" (Edge-core ECS4150-54T)
          for special orders only
          Net Price: 1 000.00 USD
          product card»
      • » 10-GIGABIT ETHERNET
          #09771

          Managed switch, 48x 10/100/1000 RJ-45, 4 slide-in SFP+ 10G slot, 19" (TP-Link SG5452X)

          • 48× Gigabit RJ45 ports and 4× 10 Gbps SFP+ slots
          • 176 Gbps switching capacity per unit
          • Physical Stacking up to 8 units for built-in redundancy and performance**
          • L3 features: RIP, OSPF, ECMP, VRRP, PIM-DM, PIM-SM, and DHCP Server/Relay
          • Security Strategies: ACL, Port Security, DoS Defend, 802.1X
          • Highly Available with two internal fixed power supplies, VRRP, and ERPS
          • Centralized cloud management via the Omada SDN controller
          • Standalone management via web, CLI, SNMP, and RMON
          Ports 48× 10/100/1000 Mbps RJ45 Ports,
          4× 1/10G SFP+ Slots,
          1× USB 2.0 Ports,
          1× RJ45 Console Port,
          1× USB Type C Console Port,
          Fan Quantity 0
          Software features
          Quality of Service Support 802.1p CoS/DSCP priority,
          Support 4 priority queues,
          Queue scheduling- SP,
          WRR,
          SP+WRR,
          Port/Flow- based Rate Limiting
          L3 Features IP Interfaces,
          IPv4 Max 256,
          IPv6 Max 256,
          Static Routing,
          IPv4 Max 2,048,
          IPv6 Max 1,024,
          Host Route Table Max 15,300 entries,
          RIP Version v1/v2,
          Max 102,400,
          RIPng Max 51,200,
          OSPF Version v2/v3;,
          v2 Max 102,400,
          v3 Max 51,200,
          VRRP Version v2/v3,
          Max 64 groups,
          ECMP 256 entries,
          max 32 ECMP Nexhops per Destination,
          Static ARP,
          1,024 static entries,
          Dynamic ARP,
          24,576 dynamic entries,
          Proxy ARP,
          DHCP Server,
          Max 64 IP Pools,
          Max 1,000 Manual Binding Entries. DHCP Relay,
          Relayed Interface,
          Relayed VLAN
          L2 and L2+ Features DHCP Relay,
          DHCP VLAN Relay,
          DHCP L2 Relay,
          Link Aggregation,
          Static link aggregation,
          802.3ad LACP,
          Up to 8 aggregation groups and up to 8 ports per group,
          Spanning Tree Protocol,
          802.1D STP,
          802.1w RSTP,
          802.1s MSTP,
          STP Security TC Protect,
          BPDU Filter/Protect,
          Root Protect,
          Loopback Detection,
          Flow Control,
          802.3x Flow Control,
          Mirroring,
          Port Mirroring,
          CPU Mirroring,
          One-to-One,
          Many-to-One,
          Flow-Based,
          Ingress/Egress/Both,
          Device Link Detect Protocol (DLDP),
          802.1ab LLDP/ LLDP-MED
          L2 Multicast 511 IPv4,
          IPv6 shared multicast groups,
          IGMP Snooping,
          IGMP v1/v2/v3 Snooping,
          Fast Leave,
          IGMP Snooping Querier,
          Static Group Config,
          Multicast VLAN Registration (MVR),
          Multicast Filtering,
          MLD Snooping,
          MLD v1/v2 Snooping,
          Fast Leave,
          MLD Snooping Querier,
          Static Group Config,
          Limited IP Multicast (256 profiles and 16 entries per profile)
          IPv6 Support IPv6 Dual IPv4/IPv6,
          Multicast Listener Discovery (MLD) Snooping,
          IPv6 neighbor discovery (ND),
          Path maximum transmission unit (MTU) discovery,
          Internet Control Message Protocol (ICMP) version 6,
          TCPv6/UDPv6,
          IPv6 applications,
          DHCPv6 Client,
          Ping6,
          Tracert6,
          Telnet (v6),
          IPv6 SNMP,
          IPv6 SSH,
          IPv6 SSL,
          Http/Https,
          IPv6 TFTP
          VLAN VLAN Group,
          Max. 4K VLAN Groups,
          802.1Q tag VLAN,
          MAC VLAN,
          Protocol VLAN,
          GVRP,
          Voice VLAN
          Security AAA,
          802.1X,
          Port based authentication,
          MAC (Host) based authentication,
          Authentication Method includes PAP/EAP-MD5,
          MAB,
          Guest VLAN,
          Support Radius authentication and accountability,
          IP/IPv6-MAC Binding,
          512 Binding Entries,
          DHCP Snooping,
          DHCPv6 Snooping,
          ARP Inspection,
          ND Detection,
          IP Source Guard,
          253 Entries,
          Source IP+Source MAC,
          IPv6 Source Guard,
          183 Entries,
          Source IPv6 Address+Source MAC,
          DoS Defend,
          Static/Dynamic/Permanent Port Security,
          Up to 64 MAC addresses per port,
          Broadcast/Multicast/Unicast Storm Control,
          kbps/ratio control mode,
          Port Isolation,
          Secure web management through HTTPS with SSLv3/TLS 1.2,
          Secure Command Line Interface (CLI) management with SSHv1/SSHv2,
          IP/Port/MAC based access control
          Management
          Omada App Yes
          Centralized Management Omada Cloud-Based Controller,
          Omada Hardware Controller (OC300),
          Omada Hardware Controller (OC200),
          Omada Software Controller
          Cloud Access Yes (Through OC300,
          OC200,
          Omada Cloud-Based Controller,
          or Omada Software Controller)
          Management Features Web-based GUI,
          Command Line Interface (CLI) through telnet,
          SNMPv1/v2c/v3,
          SNMP Trap/Inform,
          RMON (1,2,3,9 groups),
          SDM Template,
          DHCP/BOOTP Client,
          Dual Image,
          Dual Configuration,
          CPU Monitoring,
          Cable Diagnostics,
          EEE,
          SNTP,
          System Log
          Switching capacity [Gbps] 176 Gbps
          Stacking Number 8,
          Stacking Port 10G SFP+ Slot (all uplink ports can be used as stacking ports),
          Stacking Bandwidth Up to 40 Gbps (max 2 stacking ports)
          Packet Forwarding Rate 130.94 Mp/s
          MAC Address Table 16 K
          Jumbo Frame 9 KB
          Housing / case type Rack Mountable
          Dimensions 17.3 × 8.7 × 1.7 in (440 × 220 × 44 mm)
          Operating temperature -5°C ÷ 45°C
          Operating humidity 10% ÷ 90%,
          non-condensing
          Power Two field-replaceable and hot-swappable redundant power supplies (100–240 VAC,
          50/60 Hz),
          *Ships with one PSM550-AC module by default,
          and another field-replaceable redundant power supply requires a separate purchase.
          Max Power Consumption 34.1 W (220V/50Hz @ 25 °C),
          34.3 W (110V/60Hz @ 25 °C)
          Max Heat Dissipation 116.42 BTU/hr (220V/50Hz @ 25 °C),
          117.10 BTU/hr (110V/60Hz @ 25 °C)
          Certificates CE,
          FCC,
          RoHS
          Warranty period 5 years
          Manufacturer TP-Link
          TP-LINK
          Managed switch, 48x 10/100/1000 RJ-45, 4 slide-in SFP+ 10G slot, 19" (TP-Link SG5452X)
          Net Price: 723.00 USD
          product card»

top
